Koike Aronsan Welding Positioner, Head Stock/Tail Stock Positioner, Model HTS240VF, New 2011

Capacity:

  • ROTATION (LOAD TORQUE LBS.): 1,440,000
  • CAPACITY BETW. HEAD/TAIL STOCK: 240,000 LBS. AT 6” OF CENTER
  • TABLE SIZE: 84 ” X 84 “
  • TABLE SPINDLE SIZE: 12 “
  • TABLE ROTATION SPEEDS: .4 – .008 RPM
  • RAIL GUAGE:  83 ½ “
  • RAIL LENGTH: 64 ‘
  • ROTATION: 20 HP
  • TOTAL WEIGHT: 87,728 LBS.

Equipped With:



  • T SLOTTED TABLES
  • PENDANT CONTROLS
  • VARIABLE SPEED ROTATION
  • HS 120 HEAD STOCK, 120,000 LBS. AT 12 ” OVERHANG
  • HS 120 TAIL STOCK, 120,000 LBS AT 12 ” OVERHANG
  • 48 INCH RISERS BLOCKS



  • Note: This system was never used. Condition as new. Currently in storage.



Please contact us for additional information, pictures, and pricing!
